  • D580


  • OrcaTorch D580 is a professional underwater dive light with max 530 lumens output. Mechanically head rotary switch offers high reliability underwater. The light is compatible with two types of batties: 1* 18650Li-ion rechargeable battery, which is economic and eco-friendly, and the 3*AAA Alkaline batteries, which is low cost and easy to get. It has 6 degrees super narrow beam, quite suitable for recreational diving as a primary light, and for technical diving as a backup light.

  • Featuring

    * Uses CREE LED, max 530 lumens

    * Uses 3*AAA battery, compatible with 1*18650 battery

    * 6° beam angle

    * Mechanically head rotary switch offers high-reliability underwater

    * Intelligent Over-Heat protection

    * Water pressure resistant construction, depth rated to 150 meters

    * Reverse polarity protection, to protect from improper battery installation

    * Over-discharge protection function

    * Constructed from high-strength A6061-T6 aluminum

    * Mil-Spec Type III hard anodized finish for durability and corrosion resistance

    * Two sides coated toughened glass with high water pressure resistance under deep water

Share to:

Battery Mode3*AAA Battery1*18650 Battery


Runtime2h 50mins3h 30mins
Beam Distance

179m (on land)

Impact Resistance1.5m
WaterproofUnderwater 150m
Working Voltage3-4.8V

128.5mm(Length) x 27mm(Tube Diameter) x35.5mm(Head Diameter)

Net Weight123g(Excluding Battery)
Accessories3*AAA Battey, Battey Shield, Brand rubber bands, Spare O-rings, Lanyard


Stated data has been measured according to the international flashlight test standards ANSI/NEMA FL1 using one 18650 Li-ion battery (3.7V, 3400mAh) and three Gassner AAA Alkaline battery under laboratory conditions. The parameters are approximate and may vary between flashlights, batteries, and environments.
